US 1100 TubeChiller With Integrated Watercooler Unit

Request Price Now

P/N 79.500.200/79.500.800.350

Highlights

  • - Combines shrinking with immediate cooling, without the operator coming into contact with the hot shrink holder
  • - Changeable adaptors for SK/CAT/BT 30 to 50 and HSK 25 to 100 are available
  • - Manual operation with power button or automatic with parameters
  • - Innovative pyrometer coil with TempControl for monitoring the shrink temperature (optional)
  • - Foot switch for ‘hands free’ operation
  • - I4.0 functions of the devices
  • - Reading tool date via RFID chip, Data Matrix code or QR code
  • - Integrated data interfaces USB, RS242 for network integration
  • - Data transfer for statistical evaluations and documentation
  • - Shrink range: Ø 3 – 32mm for carbide shanks Ø 6 – 32mm for HSS shanks
  • - Maximum shrink length approx. 500mm
  • - Power: 11 kW
  • - Includes basic coil, 5 interchangeable discs, tubechiller, coolant additive 1 litre and 1 set of gloves

Description

With the „US 1100 TubeChiller®“ we offer the fully automatic solution for automatic shrinking and subsequent cooling of tools. The TubeChiller® technology was developed to combine our shrinking devices of the US 1100 series with automatic cooling by the TubeChiller®. After the shrink process, cooling takes place automatically, without the risk for the operator to have contact with hot tools. The operator places the chuck in the shrink device, pulls the coil down and starts the shrink process. After the shrink process, the cooling tube lifts up from the TubeChiller® housing. At the same time the coolant rises into the cooling tube and flows around the tool like a ring. During this movement, the induction coil is automatically moved back to its starting position without the need for an additional drive or intervention of the operator. After the cooling process, the tool holder is dried with air and ready for use in the machine.
